Description
| At Rated Voltage | 2 HP L-L / 2 HP L-N |
| Cord Range | 0.560 to 1.050 |
| Product ID | Ratings are permanently marked on device |
| Terminal Accom. | 18-10 AWG |
| Terminal ID | Brass-Hot, Green-Ground, Silver-Neutral |
| Torque Range | 10-14 in-lbs |
| Wire Gauge | 14-8 AWG |
|
ELECTRICAL SPECIFICATIONS
|
|
| Amperage | 30 A |
| Current Interrupting | Certified for current interrupting at full rated current |
| Dielectric Voltage | Withstands 2000V per UL498 |
| Grounding | Grounding |
| Pole | 3 |
| Temperature Rise | Max 30C after 250 cycles OL at 200 percent rated current |
| Voltage | 125/250 VAC |
| Wire | 4 |
